AII-2PF1000 2-Axes Double Support Positioner

  • Increasing productivity due to faster speed
  • Can be used to build varied jig systems with a large degree of positioning flexibility
  • A hole through the center of the rotary table, enabling cables and hoses to be routed through easily
Inquiry
Name  Robot 2-Axes Double Support Positioner
Model Name AⅡ-2PF1000
A2PF1001-JNN
Max. Payload Capacity 1000kg
Rotating Speed 2.9rad/sec(166°/sec)
Tilting Speed 1.4rad/sec(82°/sec)
Rotating Torque 882N・m
Tilting Torque 3704N・m
Position Repeatability ±0.08mm
(Position at R250mm)
Stop Position Random
Mass (Weight) 470kg
